Description
Heavy Duty Single & Double T-BOLT Hose Clamp
Heavy duty T bolt clamp is widely used in the high pressure hose fasten , such as fire hose ,water hose and so on .
| 1)Material: | W1 | All zinc-plated | |||||
| W2 | Screw, axle and sleeve adopt galvanized iron,others adopt 200 series or 300 series stainless steel | ||||||
| W4 | Fully adopt 200 or 300 series stainless steel | ||||||
| W5 | All stainless steel 316 | ||||||
| 2)surface handle: | Zinc-plated or stainless steel | ||||||
| 3)Band width: | 18mm/26mm | ||||||
| 4)Band thickness | Galvanized iron | Stainless steel | |||||
| 0.6mm/0.8mm/1.2mm/1.5mm/1.7mm | 0.6mm/0.6mm/0.8mm/0.8mm/1.0mm | ||||||
| 5)Screw size: | M5/M6/M8/M10 | ||||||
| 6)breaking torque | 5Nm/15Nm/25Nm/40Nm(min) | ||||||
| 7) Feature | The blankholder of the band side is not easy to scratch the pipeline , protect the pipeline | ||||||
| The pressure of the band is greater and play a role in protecting. | |||||||
|
Size |
Bandwidth |
Screw |
|
|
W1 |
W2/W4 |
||
|
17-19 |
0.6*18 |
0.6*18 |
M5*40 |
|
20-22 |
M5*40 |
||
|
23-25 |
M5*40 |
||
|
26-28 |
M5*40 |
||
|
29-31 |
0.8*20 |
0.6*20 |
M6*50 |
|
32-35 |
M6*50 |
||
|
36-39 |
M6*50 |
||
|
40-43 |
M6*50 |
||
|
44-47 |
1.2*22 |
0.8*22 |
M6*55 |
|
48-51 |
M6*55 |
||
|
52-55 |
M6*55 |
||
|
56-59 |
M6*55 |
||
|
60-63 |
M6*55 |
||
|
64-67 |
M6*55 |
||
|
68-73 |
1.5*24 |
0.8*24 |
M8*70 |
|
74-79 |
M8*70 |
||
|
80-85 |
M8*70 |
||
|
86-91 |
M8*70 |
||
|
92-97 |
M8*70 |
||
|
98-103 |
M8*70 |
||
|
104-112 |
M8*80 |
||
|
113-121 |
M8*80 |
||
|
122-130 |
M8*80 |
||
|
131-139 |
1.7*26 |
1.0*26 |
M10*90 |
|
140-148 |
M10*90 |
||
|
149-161 |
M10*110 |
||
|
155-167 |
M10*110 |
||
|
162-174 |
M10*110 |
||
|
175-187 |
M10*110 |
||
|
188-200 |
M10*110 |
||
|
201-213 |
M10*110 |
||
|
214-226 |
M10*110 |
||
|
227-239 |
M10*110 |
||
|
240-252 |
M10*110 |
||
|
253-265 |
M10*110 |
||
|
266-278 |
M10*110 |
||
|
279-291 |
M10*110 |
||
|
292-304 |
M10*110 |
||
