Description
Mobile Foam Water Dual Fire Monitor
Part 1:Product introduction
PSY30 mobile fire water cannons are fully functional and have a long range.
The system has the characteristics of small volume, light weight, folding support, simple operation, flexible and reliable
storage and transportation. The gun is particularly suited to oil fields, oil depot, airport, terminal, large buildings,
petrochemical industry, and fire is difficult to enter the old city, underground mall facilities and other poisonous and harmful
flammable and explosive high-risk places, is indispensable to fire safety facilities and equipment.
Part 2:Function introduction
1. Direct current, spray: rotating gun head, and the head from 0 to 40mm scale, water flow from spray to dc.
2, the rise and fall: rotary swing handle, barrels from 30 ° ~ 70 ° rises and falls.
3. Left and right: open lock lock, manual swing in the desired direction.
Part 3:Performance parameter
| Model | PSY30 |
| Rated working pressure （MPA） | 0.8 |
| Working pressure range (MPA) | 0.8-1.0 |
| Rated flow rate (L/S) | 30 |
|
Range elevation Angle of 30 ° |
60 |
| Spray angle | +90 |
| Pitching angle | +30-+70 |
| Horizontal turning angle | 90 |
| Weight (KG) | 9.5 |
| Connection | As require |
